TRUCK BOX BODY PANEL

TRUCK BOX BODY PANEL

In this era of efficiency, should heavy-weight materials be optimized?

Aluwell can help.

Tailor-made truck box body panels series:

  • Aluwell® X1 Steel Composite Panel

  • Aluwell® X3 Aluminum Reinforced Honeycomb Panel

The panel is thin, light, strong and impact resistant, reducing the weight of the truck body and increasing the capacity of the carriage.

Using Aluwell®X1, X3 panel, no need for a lot of brackets and rivets to fix, which effectively improve the installation efficiency. Also, it makes decorating or filming much more easier due to the flatness of the body.

Aluwell®X1 Steel Composite Panel:

Aluwell® X1 steel composite panels consist of two sheets of 0.3-0.5mm high tensile steel and plastic core. The unique composite technology tightly combines the two steel sheets with the core material.

Aluwell® X1 panel can replace the traditional 60mm complex sandwich structure of galvanized steel and PU.

X1 Steel is a high strength low alloy steel. Adding a small amount of tungsten, vanadium, silicon, molybdenum, nickel, manganese and other alloys greatly improves the strength and hardness of the steel. Among them, nickel can have higher toughness, and copper, nickel and chromium can increase corrosion resistance and prevent rust.

Benefits of Aluwell® X1 panel: Increased cargo capacity, overall reduced weight, impact resistance, easy installation. Weather-resistant, dirt-resistant and easy to maintain.


Aluwell®X1 Specifications:

  • Coating: Outer side is lacquered coated with exterior-class high performance polyester for transportation use.

  • Colors: Any color

  • Thickness: 13 mm max.

  • Width: 1,200/1,220 mm

  • Length: 12 meter max.



Aluwell® X3 Aluminum Reinforced Honeycomb Composite Panel:

Exclusive and innovative materials designed for truck rear doors.

Aluwell® X3 - On the basis of ALUMINUM HONEYCOMB PANEL, polyethylene components are added to further increase the strength.

Advantages of honeycomb panels:

  • High tensile strength

  • Superior thermal insulation and sound insulation

  • Moisture and corrosion resistant


Aluwell®X3 Specifications:

  • Coating: Outer side is lacquered coated with exterior-class high performance polyester for transportation use.

  • Colors: Any color

  • Thickness: 20-50 mm

  • Width: 1,000-1,575mm

  • Length: 5.8 meter max.
